55 PERCENT ALUMINUM GALVALUME STEEL COIL GL
The Specification of Galvalume steel coils:
Galvalume steel coil
Brand Name: Xinzheng
Standard: EN 10327:DX51D+AZ, DX52D+AZ, DX53D+AZ
EN 10326:SS250GD+AZ, SS350GD+AZ
JIS G3321:SGLCC, SGLCD, SGLCDD, SGLC 400
ASTM A792M:CS type C, CS type B, DS, SS255, SS345
Grade: SGLCC,SPCC, SPCD, SPCE, DC01, DC03, DC04, CS, DS, DDS, Q195, Q250, Q350
Thickness: 0.14mm-0.8mm
Width: 600mm-1250mm
Length: Coil or client's requirements
AluZinc Coating: 40g/m2 to 275g/m2
Spangle: regular spangle,small spangle,small spangle,zero spangle
Coil ID: 508 /610mm
Coil Weight: 3-10 Tons
Type : coil or sheets
The product detail of galvalume steel coils:
Spangle: regular spangle, Big spangle, Mini spangle and Zero spangle
Usage of galvalume steel coils
infrastructure : Roofing; External Siding; Garage; Shutter
Household Appliances :Oven; Air-Conditioning Ventilation System; Solar Water Heater; Electronics;
Automobile : Mobile Muffler; Vent Pipe; Catalysis Converter Heater Shield; Bottom Accessories;
Industrial Instrument : Electric Control Cabinet; Industrial Freezer Chest; Dispenser;
Package of galvalume steel coils or sheets
with edge protector. steel hoop and seals, or as per requirements of customers
Coil Packing
Sheet Packing
Galvalume Steel Coils and Sheets(Aluzinc Steel Coils) | ||||
| Item | GI | GF(Zn-5%Al) | GALVA-LUME (55%Al-45%Zn) | Al |
| Service Life | Fair | Fair | Good | Good |
| Electrochemical Protection | Good | Good | Good | N/A |
| Welding Performance | Good | Fair | Poor | Poor |
| Application with Wet Concrete | Good | Poor | Very Poo | Very Poor |
| Thermal Resistance | Poor | Poor | Good | Excellent |
| Specifications | ||||
| Standard | EN 10327 | DX51D+AZ, DX52D+AZ, DX53D+AZ, | ||
| EN 10326 | SS250GD+AZ, SS350GD+AZ | |||
| JIS G3321 | SGLCC, SGLCD, SGLCDD, SGLC 400 | |||
| ASTM A792M | CS type C, CS type B, DS, SS255, SS345 | |||
| Base Metal | Cold rolled steel coils (Base Material) | |||
| SPCC, SPCD, SPCE, DC01, DC03, DC04, CS, DS, DDS, Q195, Q250, Q350 ^^ | ||||
| Thickness | 0.14mm--0.8mm | |||
| Width | 600mm-1250mm | |||
| Coil ID | 508mm, 610mm | |||
| Zinc coating | 40g/m2-275g/m2 | |||
| Surface treating | chromium free passivation, chromium passivation, fingerprint resistant, oiled, color coated | |||
| Spangle types | regular spangle/Mini spangle/zero spangle | |||
| Application | ||||
| Architecture | Roofs and outside walls of civilian and industrial buildings, garage doors, fencings and window blinds | |||
| Appliances Industry | Outer clad sheets for washing machine, refrigerator, television, air conditioner and ventilation system, explosion-proof strip, solar water heater and appliance parts | |||
| Auto Industry | Muffler, heat shields of exhaust pipe and catalytic converter, auto parts & accessories under the frame, signboard in highway. | |||
| Industrial Instruments | Electric control cabinet, industrial refrigeration equipment, automatic vending machine | |||
| Packing | ||||
| With edge protector. Steel hoop and seals, or as per requirements of customers. | ||||
| Delivery Time | ||||
| 15days-30days | ||||
| Pay Terms | ||||
| T/T L/C at sight | ||||
